Title (srp)

Numeričko eksperimentalna istraživanja nestacionarnih strujanja u postrojenjima sa cross-flow turbinama

Author

Svrkota, Dragan M., 1962-

Contributor

Stamenković, Živojin, 1972-
Tašin, Slobodan
Bogdanović Jovanović, Jasmina
Spasić, Živan
Kocić, Miloš

Description (srp)

Transients in hydropower plants can result in serious disturbances in aplant operation and damage of equipment. The best way to prevent suchadverse outcomes is to conduct a transient-state analysis using amathematical model of the hydropower plant system.Based on the collected data on 270 hydropower plants with cross-flowturbines, regression analyses were done and regression equations werederived that relate a cross-flow turbine specific speed (ns), turbine ratedspeed (nt), turbine runner diameter (D1) and turbine runner width (B1)and jet (B) as a function of turbine head and discharge.The obtained equations were used to estimate the turbine performancecharacteristics using available unit hill charts of three different cross-flowturbines (ns=45.7, 68.8 i 93.4). Finally, the estimated performancecharacteristics were used to form the boundary condition “CROSSFLOWTURBINE” within the unsteady 1D mathematical model.The model was validated through case studies by comparing calculatedand measured changes in the turbine speed and turbine inlet pressure,induced by sudden load rejection. The difference between the calculatedand measured peak pressures was up to 10% during the critical period,(from the moment of load rejection up to the guide vanes closure). In thecase of turbine speed, the difference between the peak values was lessthan 10% in the same period.

Description (srp)

Bibliografija: str. 146-149 Datum odbrane: 13.10.2023. Energy and process technology

Object languages

Serbian

Date

2023

Rights

This work is licensed under a
CC BY-NC-ND 3.0 AT - Creative Commons Attribution-NonCommercial-NoDerivs 3.0 Austria License.

http://creativecommons.org/licenses/by-nc-nd/3.0/at/legalcode
